Omron NS HMI NS5-SQ10B-ECV2
Specifications
1. NEW AND ORIGINAL OMRON touch panel monitor
2. NS series 5.7 inch 256 color STN
3. 2* RS232, 1* USB Slave, 60MB Memory
NS-Series caters for all your application needs!
Enhanced networking features, image progress, easy configuration and libraries allow users to create interfacing screen in no time, thus cutting man-hour cost.
Models Available | |||||||
TYPE | NS15-V2 | NS12-V2 | NS10-V2 | NS8-V2 | NS5-V2 | NS5-V2 | |
Dimensions | 405 304 70 mm | 315 x 241 x 48.5 mm | 232 x 177 x 48.5 mm | 195 x142 x54 mm | |||
Effective display area | 15 inch | 12.1 inch | 10.4 inch | 8 inch | 5.7 inch | ||
Display device | TFT | STN/TFT | Monochrome STN | ||||
Number of dots | 1024 x 768 dots | 800 x 600 dots | 640 x 480 dots | 320 x 240 dots | |||
Display color | 256 colors | 16 shades of gray | |||||
BMP/JPEG Display | 32,768 color | 4,096 / 32,768 colors | - | ||||
Color Video Display | 260,000 colors | - | - | ||||
Color | 60 Mbytes | ||||||
Screen Capacity | |||||||
USB Port | |||||||
Memory Card | |||||||
Ladder Monitor function | - | - | |||||
Video Input Unit support | - | - | |||||
Control Link | - | - | - | ||||
Interface Unit Support | |||||||
PictBridge | (see note) | (see note) | |||||
ORDERING | |
5.7-inch | |
NS5-MQ10-V2 | 5.7-inch,STN monochrome,Ivory |
NS5-MQ10B-V2 | 5.7-inch,STN monochrome,Black |
NS5-MQ11-V2 | 5.7-inch,STN monochrome ,Ivory,Ethernet |
NS5-MQ11B-V2 | 5.7-inch,STN monochrome ,Black,Ethernet |
5.7-inch | |
NS5-SQ10-V2 | 5.7-inch,STN,COLOR,Ivory |
NS5-SQ10B-V2 | 5.7-inch,STN,COLOR,BLACK |
NS5-SQ11-V2 | 5.7-inch,STN,COLOR,Ivory,Ethernet |
NS5-SQ11B-V2 | 5.7-inch,STN,COLOR,BLACK,Ethernet |
NS5-TQ10-V2 | 5.7-inch,STN,COLOR,Ivory |
NS5-TQ10B-V2 | 5.7-inch,STN,COLOR,BLACK |
NS5-TQ11-V2 | 5.7-inch,STN,COLOR,Ivory,Ethernet |
NS5-TQ11B-V2 | 5.7-inch,STN,COLOR,BLACK,Ethernet |
8.4-inch | |
NS8-TV00-V2 | 8.4-inch,STN,COLOR,Ivory |
NS8-TV00B-V2 | 8.4-inch,STN,COLOR,BLACK |
NS8-TV01-V2 | 8.4-inch,STN,COLOR,Ivory,Ethernet |
NS8-TV01B-V2 | 8.4-inch,STN,COLOR,BLACK,Ethernet |
10.4-inch | |
NS10-TV00-V2 | 10.4-inch,STN,COLOR,Ivory |
NS10-TV00B-V2 | 10.4-inch,STN,COLOR,BLACK |
NS10-TV01-V2 | 10.4-inch,STN,COLOR,Ivory,Ethernet |
NS10-TV01B-V2 | 10.4-inch,STN,COLOR,BLACK,Ethernet |
12.1-inch | |
NS12-TS00-V2 | 12.1-inch,STN,COLOR,Ivory |
NS12-TS00B-V2 | 12.1-inch,STN,COLOR,BLACK |
NS12-TS01-V2 | 12.1-inch,STN,COLOR,Ivory,Ethernet |
NS12-TS01B-V2 | 12.1-inch,STN,COLOR,BLACK,Ethernet |
15 -inch | |
NS15-TS00-V2 | 15 -inch,STN,COLOR,Ivory |
NS15-TS00B-V2 | 15 -inch,STN,COLOR,BLACK |
NS15-TS01-V2 | 15 -inch,STN,COLOR,Ivory,Ethernet |
NS15-TS01B-V2 | 15 -inch,STN,COLOR,BLACK,Ethernet |
Cable | |
XW2Z-200T | NS-series PT Connecting |
XW2Z-500T | 5M |
NSH5 Cables | |
NSH5-422CW-10M | 10M |
NSH5-232CW-3M | 3M |
